Answer
Suzuki Coupling Reaction: Detailed Explanation
What is Suzuki Coupling?
The Suzuki-Miyaura coupling reaction is a palladium-catalyzed cross-coupling reaction that forms carbon–carbon (C–C) bonds between an organoboron compound and an organohalide.
It typically uses a palladium catalyst such as Pd(PPh3)4 and a base like NaOEt.
Mechanism Overview
- Oxidative Addition: Pd(0) inserts into the carbon–halogen bond of the halide to form a Pd(II) complex.
- Transmetalation: The organoboron transfers its organic group to the palladium center with the help of a base.
- Reductive Elimination: The two organic groups couple to form the final product and regenerate Pd(0).
Reaction Context
In the provided reaction, a vinyl boronic ester couples with a vinyl halide under the influence of
Pd(PPh3)4 and NaOEt.
The reaction leads to the formation of a conjugated diene structure through a vinyl–vinyl coupling.
Product Analysis
The final product is typically a 1,3-diene, often with E,E-configuration if no steric hindrance or electronic bias dictates otherwise.
This structure results from the coupling of two vinyl groups into a conjugated system, such as:
Conclusion
- Reaction type: Suzuki-Miyaura coupling
- Key reagents: Vinyl boronic ester, Vinyl halide, Pd(PPh₃)₄, NaOEt
- Product: Conjugated diene (E,E-isomer in most cases)
- Steps involved: Oxidative addition → Transmetalation → Reductive elimination
